Technical Specification
|
|
-
|
4.5
Light
|
6.0
Light
|
|
Height
of Center
|
165mm
|
165mm
|
|
Swing
Over Bed
|
330mm
|
330mm
|
|
Swing
Over Slide
|
190mm
|
190mm
|
|
A.B.C.
|
600mm
|
1000mm
|
|
-
|
TRAVEL
|
TRAVEL
|
|
Cross
Slide
|
180
|
180
|
|
Top
Slide
|
125
|
125
|
|
Metric
Thread
|
1
to 6 mm
|
1
to 6 mm
|
|
-
|
SPINDLE
|
SPINDLE
|
|
Bore
|
40
|
40
|
|
Nose
|
Thread
|
Thread
|
|
Speed-8
R.P.M.
|
45
to 1000
|
45
to 1000
|
|
-
|
THREAD
|
THREAD
|
|
Thread
Per Inch
|
4
to 60
|
4
to 60
|
|
-
|
OTHER
|
OTHER
|
|
Lead
Screw TPI
|
4
|
4
|
|
Tail
Stock Sleeve Mt.
|
3
|
3
|
|
Power
Required (h.P.)
|
1.5
|
1.5
|
|
|
 |
 |
